Astm B139 Hex Bar Supplier, Pb102 Flat Bar Exporter, Ph Bronze C52400 Rectangular Bar Stock, Ph Bronze Rod Dealer, Phosphor Bronze C52100 Bright Bar, Phosphor Bronze Round Bar Manufacturer In India
Mahavir Metal Corporation is a premier Phosphor Bronze Rod Manufacturers in India. We offer special strength and resistance to corrosion ASTM B316 Phosphor Bronze Rod for various industrial uses. These UNS C62500 copper alloy rods manufactured by high standards and accurate techniques are very popular in marine applications as well as aerospace and engineering.
We make sure that industries with high demand for ASME SB150 Phosphor Bronze Rod Bar having increased wear resistance and machinability have access to the best quality ASTM B150 aluminum bronze bar available in the market.
Phosphor Bronze Round Bar Supplier, Phosphor Bronze Rods, ASME SB139 Phosphor Bronze Bar, Bronze Hollow Bar, UNS C51000 Round Bars, Aluminium Bronze Bar Manufacturer, ASTM B139 Phosphor Bronze Rod Manufacturer in India
Mahavir Metal Corporation is a reputed Phosphor Bronze Rod Manufacturers and Supplier in India. We supply Phosphor Bronze Rod HR Square Bar, and our exclusive range of UNS C53400 bronze bar Dealer products. Being a reputed Phosphor Bronze Rod Hex Bar Supplier, we guarantee timely supply of high quality engineered products across the globe. Also, we provide qualitatively high Phosphorous Bronze Bush Bars and Phosphorous Bronze Rod Square Bars for varieties of Industries. We proved are selves as one of the premier ASTM B139 UNS C52100 hollow bar Manufacturers, We are also a leading supplier of Phosphorous Bronze Bush.
Phosphorous Bronze Rod Specifications
Standard :
- ASTM B139: Specification for phosphorus bronze rods, bars, and shapes.
- BS 2874: British standard for phosphorus bronze rods and bars.
Testing of PB Round Bars
- Tensile Strength: Ability of the rod to withstand pulling or stretching forces.
- Hardness Test: Assesses the resistance of the rod to deformation.
PB Round Bar Features
- High Strength: Excellent tensile strength for use in high-stress applications.
- Good Corrosion Resistance: Ideal for marine environments.
Sizes (Diameter) Lengths
- 3mm to 250mm
- Standard: 1 meter to 6 meters
- Custom lengths available upon request
Grades Availables of Phosphorous Bronze Rod
These Phosphor Bronze Rods are available in several grades ASTM B139 UNS C52100 is particularly appropriate for applications where high tensile strength and wear qualities are desirable; UNS C52400 which offers improved service strength; and C51000, characterized by improved machinability. C95900 and C95800 are the most suitable for marine applications because they have corrosion capability.
Size Range of Phosphor Bronze Rod
| ROUND RODS | 3 mm dia to 400 mm |
| HEX | 10mm To 60mm |
| SQUARE | 20 mm to 200 mm |
| FLAT | 0.10 mm thickness to 100 mm thickness & maximum width 360 mm |
| BILLETS | Up to 200 mm |
| INGOTS | As per Specification |
Weight Chart of Phosphorus Bronze Round Bars
| Diameter (inh) | Diameter (MM) | Weight chart (Kg/m) | Weight chart (lbs/feet) |
| 3/32 | 2.39 | .038 | .023 |
| 3/16 | 4.77 | .147 | .099 |
| 1/8 | 3.19 | 0 .066 | .044 |
| 1/4 | 6.4 | .268 | .18 |
| 17/32 | 13.5 | 1.190 | .80 |
| 7/16 | 11.12 | .81 | .54 |
| 15/32 | 11.91 | .92 | .62 |
| 9/16 | 14.3 | 1.33 | .89 |
| 5/8 | 15.88 | 1.64 | 1.1 |
| 7/8 | 22.23 | 3.21 | 2.16 |
| 3/4 | 19.05 | 2.36 | 1.58 |
| 13/16 | 2.65 | 2.76 | 1.86 |
| 15/16 | 23.82 | 3.68 | 2.47 |
| 1 | 25.5 | 4.18 | 2.81 |
| 1 3/16 | 3.17 | 5.90 | 3.97 |
| 1 1/16 | 26.99 | 4.72 | 3.18 |
| 1 1/8 | 28.58 | 5.29 | 3.56 |
| 1 1/4 | 31.75 | 6.54 | 4.39 |
| 1 1/2 | 38.1 | 9.45 | 6.32 |
| 1 5/16 | 33.34 | 7.21 | 4.84 |
| 1 3/8 | 34.93 | 7.91 | 5.32 |
| 1 5/8 | 41.28 | 11.04 | 7.42 |
| 2 | 5.80 | 16.72 | 11.24 |
| 1 3/4 | 44.45 | 12.8 | 8.61 |
| 1 7/8 | 47.63 | 14.70 | 9.88 |
Thermal Properties of ASME SB139 Phosphor Bronze Round Bars
| Thermal Properties | Metric | English |
| CTE, linear | 17.8 µm/m-°C Temperature 20.0 - 300 °C | 9.89 µin/in-°F Temperature 68.0 - 572 °F |
| Specific Heat Capacity | 0.380 J/g-°C | 0.0908 BTU/lb-°F |
| Thermal Conductivity | 84.0 W/m-K Temperature 20.0 °C | 583 BTU-in/hr-ft²-°F Temperature 68.0 °F |
| Melting Point | 975 - 1060 °C | 1790 - 1940 °F |
| Solidus | 975 °C | 1790 °F |
| Liquidus | 1060 °C | 1940 °F |
| Annealing Point | 482 - 677 °C | 900 - 1250 °F |
Phosphor Bronze Rod Chemical Composition
| Alloy number | Sn | P | Pb | Zn | Cu+Sn+P |
| C5191 | 5.5-7.0 | 0.03-0.35 | ≥99.5 | ||
| C5441 | 3.0-4.5 | 0.01-0.50 | 3.5-4.5 | 1.5-4.5 | ≥99.5 |
Phosphor Bronze Rod Mechanical Properties
| Grade B.S. 1400: 1985 |
Nominal Composition |
2% PS N/mm Min |
Tensile Strength N/mm Min |
Elongation % Min |
Brinell Hardness Min |
| PB1 | 89/10/01 | 130 | 250 | 5 | 60 |
| PB1 | 88/12 | 140 | 260 | 7 | 80 |
| PB1 | 90/10 | 130 | 250 | 5 | 60 |
| PB1 | 90.5/9.5 | 130 | 240 | 5 | 80 |
| LPB-1 | 87/8/2/3 | 80 | 175 | 7 | 60 |
| Pb2 | 88/12 | 120 | 195 | 5 | 60 |
| Pb2 PB |
88/12 95/5 |
145 130 |
295 240 |
5 5 |
80 80 |
Applications of Phosphor Bronze Rod
Phosphor Bronze Rod Manufacturers in India
- Mahavir Metal Corporation
Packing of Phosphor Bronze Rod
We apply the safest and most efficient means of packaging for every kind of delivery.
- Wooden Boxes
- Wooden Pallets
- Shrink-Wrapp
- Gunny Bags
Ready Stock of Phosphorous Bronze Rod in India
- Phosphor Bronze Hex Bar
- Uns C51000 Forged Round Bars
- Phosphor Bronze Polished Bar
- Uns C53400 Bright Drawn Round Bar
- Ph Bronze Hot Rolled Bars
- Asme Sb139 Bar Stock
- Ph Bronze Cold Drawn Bars
- Astm B139 Billet
- Phosphor Bronze Square Bar
- Phosphor Bronze Hollow Bar
- Phosphor Bronze Flat Bar
- Phosphor Bronze Precision Ground Stock
- Phosphor Bronze Hexagonal Bar
- Phosphor Bronze Round Bar
- Phosphor Bronze Precision Ground Bar
- Phosphor Bronze Rectangular Bar
- Astm B139 C54400 Cold Finished Round Bars
- Ph Bronze Alloys Shaft
- Phosphor Bronze Annealed Bars
Phosphorous Bronze Rod Supplier in India :
We have over tons of Phosphorous Bronze Rod in stock. We are one of India’s leading suppliers of Phosphor Bronze C54400 Bars. We also Accept customized C510 Phosphor Bronze Round Rod orders as per the client's requirements from Mumbai, Navi Mumbai, Chennai, Hyderabad, and many more.
Phosphorous Bronze Rod Supplier & Exporters in India :
Mahavir Metal Corporation is a renowned supplier and exporter of premium-quality ASTM B139 Phosphor Bronze Rod. Established across numerous countries worldwide, we proudly uphold our reputation as one of the leading Phosphor Bronze Rod manufacturers on the global stage.
