Aluminium Alloy Plate, Aluminium Bronze Plates Supplier, Aluminium Bronze Plate, Aluminium Bronze Plate Manufacturer in India
Mahavir Metal Corporation is a noteworthy Aluminium Bronze Plate Manufacturers in India. Our range of C-95800 Aluminium Bronze Plates Create a product of high strength and excellent resistance to corrosion as well as an optimum durability that makes it ideal to use in marine, aerospace and heavy engineering industries. We follow all specifications of UNS CA-104/C-95400 to make sure the Aluminium Bronze Plates we deliver to the market performs to the highest standards in the market.
Our Aluminium Bronze Sheets are also available in various different size, thickness, and dimensions to cater for any project. You can check our range of sheets based on weight and dimensions that you require. We are one of the leading NES 833 Aluminium Bronze Sheet Manufacturers in Mumbai and our alloys provide you with the best value for your money investing in durable and performance enhancing alloy products of the finest quality.
Aluminium Flat Rods, Aluminium Alloy Plate Exporter Mumbai, Aluminium Bronze Flat Bar Manufacturer in India
Mahavir Metal Corporation is a one of the biggest Aluminium Bronze Plate Manufacturers and Supplier in India. It is our guarantee to provide our customers with PED Approved UNS Cw307G/CA104 Aluminium Bronze Sheets of high uniformity and accuracy. Products are made to international standards while valued for their high mechanical characteristics including tensile strength, hardness, and wear/corrosion resistances. Our products can be used in cases where sheets are needed for marine requirements or for standard industrial purposes. Take a look at our price list and find out how much a new website would cost in Mumbai today.
Aluminium Bronze Plate Specifications
Superior Toughness:
- Excellent resistance to impact and shock loads.
- Ideal for applications in marine and offshore industries.
Increased Strength:
- Enhanced tensile strength compared to cold-rolled materials.
- Suitable for structural applications
Improved Performance Under High Temperatures:
- Maintains strength and integrity even at elevated temperatures.
- Suitable for applications in heat exchangers.
Sizes (Diameter) Lengths
- 2mm to 100mm (or as required).
- Width:Up to 4 Feet
- Length: Up to 8 Feet
Types of Aluminium Bronze Plate
Grades Availables of Aluminium Bronze Plate
These aluminium bronze Plates are available in several grades C95400 is particularly appropriate for applications where high tensile strength and wear qualities are desirable; C95500 which offers improved service strength; and C95200, characterized by improved machinability. C95900 and C95800 are the most suitable for marine applications because they have corrosion capability.
Alu bronze annealed plate physical property
| Properties | Yield strength | Poisson’s ratio | Elastic modulus | Charpy impact | Machinability | Izod impact | Shear modulus |
| (M30 and O61 tempers) | (@ 18.0 to 100°C/ -0.400 to 212°F, keyhole) | (@ 18.0 to 100°C/ -0.400 to 212°F) | |||||
| Metric | 380 MPa | 0.34 | 117 GPa | 3.00 J | 20 | 3.00 J | 42.3 GPa |
| Imperial | 55100 psi | 0.34 | 17000 ksi | 2.21 ft-lb | 20 | 2.21 ft-lb | 6140 ksi |
C61400 aluminum bronze plate weight chart
| Size in inch | Thickness | Weight in lbs per sheet | lbs per sq. ft |
| .063 | – | 66.744 | 2.781 |
| 1/8 | .125 | 153.9 | 5.130 |
| 1/8 | .125 | 19 .24 | 5.130 |
| 3/16 | .188 | 307.8 | 7.700 |
| 1/4 | .25 | 225.75 | 1 .750 |
| 1/4 | .25 | 430 | 1 .750 |
| 3/8 | .375 | 615.6 | 15.390 |
| 3/8 | .375 | 628.425 | 15.390 |
| 1/2 | .5 | 615.6 | 2 .520 |
| 1/2 | .5 | 666.9 | 2 .520 |
| 1/2 | .5 | 82 .8 | 2 .520 |
| 1/2 | .5 | 985 | 2 .520 |
| 3/4 | .75 | 1231 | 32.190 |
| 3/4 | .75 | 1483 | 32.190 |
| 1 | 1.00 | 1641.6 | 41.040 |
| 1 ½ | 1.50 | 206 .16 | 64.380 |
| 1 ½ | 1.50 | 309 .24 | 64.380 |
| 2 | 2.00 | 2064 | 86.000 |
Aluminium Bronze Plate Chemical Composition
| Grade | Al | Fe | Mn | Cu | Pb | Si | P | Zn | Sn | Ni | Impurity |
| C61900 | 8.0-10.0 | 2.0-4.0 | 0.5 | margin | 0.01 | 0.1 | 0.01 | 1 | 0.1 | 1.7 | |
| C62300 | 8.5-10.0 | 2.0-4.0 | 1.0-2.0 | margin | 0.03 | 0.1 | 0.01 | 0.5 | 0.75 | ||
| C63000 | 9.5-11.0 | 3.5-5.5 | 0.3 | margin | 0.02 | 0.1 | 0.01 | 0.5 | 0.1 | 3.5-5.5 | 1 |
Aluminium Bronze Plate Mechanical Properties
| Grade | Tensile Strength | 0.2% Proof Stress | Hardness | Elongation |
| CA 104 plate | 720 to 820 N/mm² | 420 to 500 N/mm² | 200 to 240 HV | 25 to 15 % |
Applications of Aluminium Bronze Plate
Aluminium Bronze Plate Manufacturers in India
- Mahavir Metal Corporation
Packing of Aluminium Bronze Plate
We apply the safest and most efficient means of packaging for every kind of delivery.
- Wooden Boxes
- Wooden Pallets
- Shrink-Wrapp
- Gunny Bags
Ready Stock of Aluminium Bronze Plate in India
- Aluminium Bronze Sheet Supplier India
- Aluminium Bronze Plate Manufacturer India
- Aluminium Bronze Alloy Plates
- C95800 Aluminium Bronze Plate India
- Aluminium Bronze Plates for Marine Industry
- ASTM B150 Aluminium Bronze Plate
- Aluminium Bronze Plate Exporter India
- Aluminium Bronze Plate Stockist India
- Aluminium Bronze Hot Rolled Plates
- Aluminium Bronze Plate Price India
- Aluminium Bronze Plate Stock India
- Aluminium Bronze Plate Supplier Mumbai
- UNS C95800 Aluminium Bronze Plates
- Aluminium Bronze Plate Application
- High-Strength Aluminium Bronze Plate
- Aluminium Bronze Plate for Aerospace
- Aluminium Bronze Plate Supplier for Heavy Industries
- Aluminium Bronze Plate for Chemical Industry
- Aluminium Bronze Plate Chemical Composition
- Aluminium Bronze Plates for Industrial Use
Aluminium Bronze Plate Supplier in India :
We have over tons of Aluminium Bronze Plate in stock. We are one of India’s leading suppliers of ASTM B148 UNS C95400 C95400 Aluminum Bronze Sheet. We also Accept customized 954 Aluminum Bronze Round Bar orders as per the client's requirements from Mumbai, Navi Mumbai, Chennai, Hyderabad, and many more.
Aluminium Bronze Plate Supplier & Exporters in India :
Mahavir Metal Corporation is a renowned supplier and manufacturer of premium-quality Aluminium Bronze Plate. Established across numerous countries worldwide, we proudly uphold our reputation as one of the leading Aluminium Bronze Plate manufacturers on the global stage.
